I.K. (Guitar Nuts, Saddles and Bridge Pins)

TUSQ Delivers Optimum Frequencies From The Strings To
The Guitar Top, Producing A Richer And Fuller Tone.
Guitar makers and players agree... acoustic guitars come alive with TUSQ man-
made ivory. TUSQ is simply more efficient at transferring vibration to your guitar
top, resulting in big open lows and clear bell like highs. TUSQ is consistent from
piece to piece, and within each piece, to offer you harmonically rich tones without
the problems associated with natural materials.

BRIDGE PINS END PINS
Model # Color Dot Shank Diameter Qty MSRP Model # Color Dot Qty MSRP
PP-1100-01 White No 0.2020”/5.14mm 6-Pcs $21.55 PP-7100-00 White No 1-Pc $12.95
PP-2100-01 Black No 0.2020”/5.14mm 6-Pcs $21.55 PP-7142-00 White Mother of Pearl 1-Pc $16.95
PP-1122-00 White 2mm Black 0.2020”/5.14mm 6-Pcs $24.95 PP-7182-00 White Paua shell 1-Pc $16.95
PP-2122-00 Black 2mm White 0.2020”/5.14mm 6-Pcs $24.95 PP-7211-00 Black No 1-Pc $12.95
PP-1142-00 White 2mm Mother of Pearl 0.2020”/5.14mm 6-Pcs $27.95 PP-7242-00 Black Mother of Pearl 1-Pc $16.95
PP-2142-00 Black 2mm Mother of Pearl 0.2020”/5.14mm 6-Pcs $27.95 PP-7282-00 Black Paua shell 1-Pc $16.95
PP-1182-00 White 2mm Paua shell 0.2020”/5.14mm 6-Pcs $27.95
PP-2182-00 Black 2mm Paua shell 0.2020”/5.14mm 6-Pcs $27.95 TUSQ bridge pins are beautifully finished in a
PP-1000-00 White 4mm Paua shell 0.1920”/4.93mm 6-Pcs $27.95 variety of color choices to compliment the woods
PP-2000-00 Black 4mm Paua shell 0.1920”/4.93mm 6-Pcs $27.95 of your instrument. Combine with TUSQ nuts and
PP-1044-00 White 4mm Mother of Pearl 0.1920”/4.93mm 6-Pcs $27.95 saddles for best results.
PP-2044-00 Black 4mm Mother of Pearl 0.1920”/4.93mm 6-Pcs $27.95 Measure the diameter of the top of the shank,
PP-4000-00 White No 0.1920”/4.93mm 6-Pcs $21.55 immediately below the collar beneath the pin
PP-3000-00 Black No 0.1920”/4.93mm 6-Pcs $21.55 head. The overall length is not important.
NUTS Left Handed Option Available
PQ-1214-00 Fender ® Jazz Style 4 String Bass Nut PQ-M600-00 Martin ® Style 1 11/16” Slotted Guitar Nut PQ-6220-00
$13.65 Fits most Fender ® Jazz 4 String Basses $13.65 Fits Martin ® Style guitars where the nut bottom and sides are angled $13.65 2” Classical Slotted Guitar Nut
LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E
Inches 1.554 0.128 0.187 1.223 Inches 1.709 0.228 0.361 1.378 Inches 2.002 0.251 0.372 1.634
Inches Approx. 1 9/16 1/8 3/16 1 7/32 Inches Approx. 1 11/16 7/32 3/8 1 3/8 Inches Approx. 2 1/4 3/8 1 5/8
Millimetres 39.47 3.25 4.75 31.06 Millimetres 43.41 5.79 9.17 35.00 Millimetres 50.85 6.38 9.45 41.50
PQ-1728-00 PQ-6060-00 1/4” Epiphone ® Style Slotted Guitar Nut PQ-6143-00
$13.65 6 String Acoustic Slotted Nut $13.65 Fits many Epiphone ® Style guitars $13.65 1/4” Slotted Nut
LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E
Inches 1.710 0.201 0.355 1.389 Inches 1.732 0.242 0.362 1.366 Inches 1.693 0.236 0.350 1.378
Inches Approx. 1 23/32 3/16 11/32 1 3/8 Inches Approx. 1 3/4 1/4 3/8 1 3/8 Inches Approx. 1 11/16 1/4 11/32 1 3/8
Millimetres 43.43 5.11 9.02 35.28 Millimetres 43.99 6.14 9.19 34.70 Millimetres 43.00 6.00 8.88 35.00
PQ-1204-00 Fender ® PrecisIon Style 4 String Bass Nut PQ-6010-00 Jumbo Gibson ® Style Slotted Guitar Nut PQ-2200-00 Standard Blank Guitar Nut
$13.65 Fits most Fender ® Precision Basses $13.65 Fits most Gibson 6 string electric guitars. $13.65 Fits most import Strat ® style guitars with a flat nut slot
LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E
Inches 1.650 0.125 0.187 1.250 Inches 1.735 0.196 0.366 1.425 Inches 1.750 0.125 0.244 NA
Inches Approx. 1 21/32 1/8 3/16 1 1/4 Inches Approx. 1 3/4 3/16 3/8 1 7/16 Inches Approx. 1 3/4 1/8 1/4 NA
Millimetres 41.91 3.17 4.75 31.75 Millimetres 44.07 4.98 9.30 36.20 Millimetres 44.45 3.17 6.20 NA
PQ-6143-00 TUSQ 1 11/16” Slotted Nut PQ-M644-00 1 3/4” Martin ® Style Slotted Guitar Nut PQ-4000-00
$13.65 Fits many guitars using a 1/4” thickness nut $13.65 Fits Martin ® Style guitars with 1 3/4” length $13.65 Jumbo 3/16” Blank Guitar Nut
LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E
Inches 1.693 0.236 0.350 1.378 Inches 1.745 0.224 0.361 1.418 Inches 1.905 0.192 0.375 NA
Inches Approx. 1 11/16 1/4 11/32 1 3/8 Inches Approx. 1 3/4 7/32 3/8 1 13/32 Inches Approx. 1 29/32 3/16 3/8 NA
Millimetres 43.00 6.00 8.88 35.00 Millimetres 44.32 5.69 9.17 36.02 Millimetres 48.39 4.88 9.52 NA
PQ-6225-00 PQ-5010-00 Fender ® Style Flat Bottom Slotted Guitar Nut PQ-4025-00 1/4” Nut Slab
$13.65 TUSQ Nut Slotted 1 5/8” $13.65 Fits many import Strats ® and Tele ® requiring a flat bottom $13.65
LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E
Inches 1.625 0.248 0.324 1.376 Inches 1.764 0.130 0.255 1.362 Inches 2.500 0.250 0.437 NA
Inches Approx. 1 5/8 1/4 5/16 1 3/8 Inches Approx. 1 3/4 1/8 1/4 1 3/8 Inches Approx. 2 1/2 1/4 7/16 NA
Millimetres 41.27 6.30 8.23 34.95 Millimetres 44.81 3.30 6.48 34.59 Millimetres 63.50 6.35 11.10 NA
PQ-M100-00 PQ-6134-00 1 3/4” Slotted Acoustic Nut PQ-4125-00
$13.65 TUSQ Blank Martin Style Nut $13.65 Fits many acoustic guitars with a 1 3/4 nut length $13.65 1/8” Nut Slab
LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E
Inches 1.89 0.226 0.420 NA Inches 1.770 0.192 0.331 1.496 Inches 2.500 0.125 7.92 NA
Inches Approx. 1 7/8 7/32 13/32 NA Inches Approx. 1 3/4 3/16 11/32 1 1/2 Inches Approx. 2 1/2 1/8 5/16 NA
Millimetres 48.01 5.75 10.67 NA Millimetres 44.96 4.88 8.41 38.0 Millimetres 63.5 3.17 7.92 NA
PQ-6116-00 1 11/16” Slotted Guitar Nut PQ-6136-00 PQ-4187-00
$13.65 Fits many acoustic guitars with a 1 11/16” nut length $13.65 1 13/16 Slotted Guitar Nut $13.65 3/16” Nut Slab
LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E
Inches 1.707 0.192 0.331 1.435 Inches 1.830 0.187 0.341 1.555 Inches 2.500 0.187 0.437 NA
Inches Approx. 1 11/16 3/16 11/32 1 7/6 Inches Approx. 1 27/32 3/16 11/32 1 9/16 Inches Approx. 2 1/2 3/16 7/16 NA
Millimetres 43.36 4.88 8.81 36.45 Millimetres 46.48 4.75 8.66 39.50 Millimetres 63.5 4.75 11.10 NA
PQ-4300-00 PQ-6226-00 PQ-6400-00
$13.65 TUSQ Taylor Classical Nut Blank $13.65 TUSQ Nut Slotted Acoustic Or Electric $13.65 TUSQ Nut Slotted Gibson Acoustic
LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E LENGTH THICKNESS HEIGHT E TO E
Inches 1.936 0.189 .305 NA Inches 1.625 0.240 0.230 1.365 Inches 1.753 0.196 0.320 1.460
Inches Approx. 1 15/16 3/16 5/16 NA Inches Approx. 1 5/8 1/4 7/32 1 3/8 Inches Approx. 1 3/4 13/64 11/32 1 15/32
Millimetres 49.17 4.80 7.75 NA Millimetres 41.15 6.10 5.84 34.67 Millimetres 44.64 4.94 8.05 37.44
